Product Description

  • All-position flux-cored wire developed to join low and medium carbon steel with 75-80% Argon / 20-25% CO2 mixed shielding gas.
  • Mixed gas operation produces a smoother arc, lower spatter, and improved bead appearance compared to CO2 variants.
  • Dual-classified E71T-1M and E71T-9M per AWS A5.20, providing maximum specification flexibility.
  • Exceptional impact properties — CVN impact values well exceed AWS A5.20 minimums at -20°C.
  • High deposition rates and excellent penetration for increased productivity in structural and heavy fabrication applications.
  • Diffusible hydrogen ≤ 8 mL/100g (H8 designation) for reduced risk of hydrogen-induced cracking.
  • ABS Approved

Technical

Chemical Composition
C Mn Si P S Cr Ni
AWS
Requirements 		0.12 max 1.75 max 0.90 max 0.03 max 0.03 max 0.20 max 0.50 max
Typical Results 0.040 1.45 0.41 0.021 0.006 0.02 0.01
Mo V Cu
AWS
Requirements 		0.30 max 0.08 max 0.35 max
Typical Results 0.01 0.01 0.017
Mechanical Properties
Tensile Strength
MPa (ksi) 		Yield Strength
MPa (ksi) 		Elongation
% 		CVN Impact
@ -20°C (J) 		Diffusible H₂
(mL/100g)
AWS
Requirements 		490–670
(70–95) 		≥ 400
(≥ 58) min 		22 min ≥ 27 ≤ 8.0 (H8)
Typical Results -
As welded 		550 (80) 475 (69) 28 112 4.7
