Product Description

  • Designed for welding materials of similar composition.
  • This alloy is an air hardening type that calls for preheat and interpass temperatures of not less than 350°F during welding.
  • Formerly known as Oxford Alloy ER505 AWS / ASME SFA 5.9.
  • Superior feedability
  • Certified Material Test Reports on all heats

Technical

Chemical Composition
CMnSiCrMoSP
0.10 max0.40-0.700.50 max8.0-10.50.8-1.20.025 max0.025 max
NiCu
0.5 max0.35 max
Mechanical Properties
Tensile Strength
MPa (ksi)		Yield Strength
MPs (ksi)		Elongation
%
AWS
Requirements		550 (80) min470 (68) min17 min
Typical Results -
As welded		640 (93)490 (71)30
