Product Description

  • Used for the welding of Monel® alloys 400, R-405, and K-500.
  • This filler metal has good strength and resists corrosion in many media, including seawater, salts, and reducing acids.
  • The weld metal of the Oxford Alloy 60 is not age hardenable and when used to join Monel® alloy K-500 it has lower strength than the base metal.
  • TIG Wire marked with AWS classification
  • Ultra clean finishing
  • Certified Material Test Reports on all heats

Technical

Chemical Composition
NiCMnFeSiCuAl
62.0-69.00.15 max4.0 max2.5 max1.25 maxBal1.25 max
TiPS
1.5-3.00.02 max0.015 max
Mechanical Properties
Tensile Strength
MPa (ksi)		Yield Strength
MPs (ksi)		Elongation
%
AWS
Requirements		480 (70) typicalNot SpecifiedNot Specified
Typical Results -
As welded		530 (77)360 (53)34
