Product Description

  • The sum of the Cr + 3.3 (Mo + 0.5W) + 16N, known as the Pitting Resistance Equivalent Number (PREN), is at least 40.
  • Designed for the welding of super duplex stainless steels UNS S32750 and S32760 (wrought) and for UNS J93380 and J93404 (cast).
  • Common industries include: Process piping, pumps & valves, and pressure vessels
  • Superior feedability
  • Certified Material Test Reports on all heats

Technical

Chemical Composition
CCrNiMoMnSiP
0.03 max24.0-27.08.0-10.52.5-4.52.5 max1.0 max0.03 max
SNCuW
0.02 max0.20-0.301.5 max1.0 max
Mechanical Properties
Tensile Strength
MPa (ksi)		Yield Strength
MPs (ksi)		Elongation
%
AWS
Requirements		Not specifiedNot specifiedNot specified
Typical Results -
As welded		850 (123)650 (94)28
