Product Description

  • Used for the welding of copper, copper-silicon, and copper-zinc base metals to themselves, and also to steel.
  • This filler metal is also used to weld on coated steels.
  • Oxford Alloy Silicon Bronze can be used to surface areas subject to corrosion.
  • TIG Wire marked with AWS classification
  • Ultra clean finishing
  • Certified Material Test Reports on all heats

Technical

Chemical Composition
Cu+AgZnSnMnFeSiAl
Bal1.0 max1.0 max1.5 max0.50 max2.8-4.00.01 max
Pb
0.02 max
Mechanical Properties
Tensile Strength
MPa (ksi)		Yield Strength
MPs (ksi)		Elongation
%
AWS
Requirements		345 (50) minNot SpecifiedNot Specified
Typical Results -
As welded		350 (51)
