Product Description

  • Used for welding low alloy high strength steels requiring good toughness at temperatures as low as -40°F (-40°C).
  • The weld deposits of this filler metal are similar to E8018-C3 electrodes.
  • Superior feedability
  • Certified Material Test Reports on all heats

Technical

Chemical Composition
CMnSiPSNiCr
0.12 max1.25 max0.40-0.800.025 max0.025 max0.80-1.100.15 max
MoVCu
0.35 max0.05 max0.35 max
Mechanical Properties
Tensile Strength
MPa (ksi)		Yield Strength
MPs (ksi)		Elongation
%
AWS
Requirements		550 (80) min470 (68) min24 min
Typical Results -
As welded		600 (87)530 (77)26
