Oxford Alloys
310T-1 FLUX CORE
Diameter: 0.045 in| Item ID | OXF310T-1.045X33 |
| AWS Spec: | 5.22 |
| AWS Class: | E310T1-1/4 |
| UNS Number: | W31031 |
| Welding Process: | FCAW |
Product Description
- Designed for all-position welding
- It is normally used for welding materials of similar composition such AISI 310 steel.
- It may also be used for welding carbon steel to stainless steel and also for welding or repairing high alloy heads and corrosion resistant castings with the same general composition.
- Vacuum packaged
- Certified Material Test Reports on all heats
Documents
Technical
| Chemical Composition | ||||||
|---|---|---|---|---|---|---|
| C | Cr | Ni | Mo | Mn | Si | P |
| 0.20 max | 25.0-28.0 | 20.0-22.5 | 0.75 max | 1.0-2.5 | 1.0 max | 0.03 max |
| S | Cu | |||||
| 0.03 max | 0.75 max | |||||
| Mechanical Properties | |||
|---|---|---|---|
| Tensile Strength MPa (ksi) | Yield Strength MPs (ksi) | Elongation % | |
| AWS Requirements | 520 (75) min | Not specified | 30 min |
| Typical Results - As welded | 610 (88) | 480 (69) | 41 |
