Product Description

  • Designed for all-position welding
  • Carbon content is below .04% and Provides superior weld performance and enhanced operator appeal.
  • Vacuum packaged
  • Certified Material Test Reports on all heats

Technical

Chemical Composition
CMnSiCrNiMoP
0.04 max0.5-2.51.0 max18.0-21.09.0-11.00.75 max0.04 max
SCu
0.03 max0.75 max
Mechanical Properties
Tensile Strength
MPa (ksi)		Yield Strength
MPs (ksi)		Elongation
%
AWS
Requirements		520 (75) minNot specified30 min
Typical Results -
As welded		580 (84)460 (67)38
