Product Description

  • Designed for the welding of 22Cr-5Ni-2Mo-0.15N duplex stainless steel (UNS S31803), commonly known as 2205.
  • Also used for welding on stainless structures where a particularly high strength is required.
  • Common industries include: Oil & Gas, Chemical, and Petrochemical
  • All position welding
  • Vacuumed packaged
  • Certified Material Test Reports on all heats

Technical

Chemical Composition
CMnSiCrNiMoP
0.04 max0.5-2.01.0 max21.0-24.07.5-10.02.5-4.00.04 max
SCuN
0.03 max0.75 max0.08-0.20
Mechanical Properties
Tensile Strength
MPa (ksi)		Yield Strength
MPs (ksi)		Elongation
%
AWS
Requirements		690 (100) min-20 min
Typical Results -
As welded		820 (119)685 (99)27
