Product Description

  • This alloy was developed to provide dense, high quality deposits with relatively high electrical conductivity for use in joining and overlay with the inert-gas processes.
  • It is primarily used to fabricate deoxidized copper and to weld repair copper castings with the gas metal arc and gas tungsten-arc processes.
  • It may also be used to weld galvanized steel and deoxidized copper to mild steel where high strength joints are not required.
  • Superior feedability
  • Certified Material Test Reports on all heats

Technical

Chemical Composition
Cu+Ag P Sn Pb Mn Si Al
98.0 min 0.15 max 1.0 max 0.02 max 0.50 max 0.50 max 0.01 max
Mechanical Properties
Tensile Strength
MPa (ksi) 		Yield Strength
MPs (ksi) 		Elongation
%
AWS
Requirements 		170 (25) min Not specified Not specified
Typical Results -
As welded 		200 (29) 55 (8) 29
