Product Description

  • Used for the welding of Inconel® alloy 617.
  • This filler metal is also used for joining various dissimilar high-temperature alloys because of its high temperature strength, oxidation resistance, and metallurgical stability.
  • Some examples are Incoloy® alloys 800HT and 802 and cast alloys such as HK-40, HP, and HP-45 Modified.
  • Superior feedability
  • Certified Material Test Reports on all heats

Technical

Chemical Composition
NiCrCoMoAlCFe
Bal20.0-24.010.0-15.08.0-10.00.8-1.50.05-0.153.0 max
MnSiSTiCuP
1.0 max1.0 max0.015 max0.60 max0.50 max0.03 max
Mechanical Properties
Tensile Strength
MPa (ksi)		Yield Strength
MPs (ksi)		Elongation
%
AWS
Requirements		620 (90)Not SpecifiedNot Specified
Typical Results -
As welded		770 (112)610 (89)28
