Product Description

  • Used for the welding of Nickel 200 and 201.
  • The reaction of titanium with carbon maintains a low level of free carbon and enables the filler metal to be used with Nickel 201.
  • Dissimilar-welding applications for Oxford Alloy 61 include joining Nickel 200 and 201 to stainless steels, carbon steels, Inconel® alloys, Incoloy® alloys, copper-nickel alloys, and Monel® alloys.
  • This filler metal is also used for joining Monel® alloys and copper-nickel alloys to carbon steels, and for joining copper-nickel alloys to Inconel® and Incoloy® alloys.
  • Superior feedability
  • Certified Material Test Reports on all heats

Technical

Chemical Composition
NiCMnFeSSiCu
93.0 min0.15 max1.0 max1.0 max0.015 max0.75 max0.25 max
AlTiP
1.5 max2.0-3.50.03 max
Mechanical Properties
Tensile Strength
MPa (ksi)		Yield Strength
MPs (ksi)		Elongation
%
AWS
Requirements		380 (55) typicalNot Specified Not Specified
Typical Results -
As welded		460 (67)260 (38)28
