Product Description

  • Designed for all-position welding
  • Carbon content is below .04 % and Provides superior weld performance and enhanced operator appeal
  • Vacuum packaged
  • Certified Material Test Reports on all heats
  • ABS Approved

Technical

Chemical Composition
CMnSiCrNiMoP
0.04 max0.5-2.51.0 max17.0-20.011.0-14.02.0-3.00.04 max
SCu
0.03 max0.75 max
Mechanical Properties
Tensile Strength
MPa (ksi)		Yield Strength
MPs (ksi)		Elongation
%
AWS
Requirements		485 (70) minNot specified30 min
Typical Results -
As welded		560 (84)460 (67)38
