Oxford Alloys 91T1-B3 FLUX CORE Diameter: 1/16 in
| Item ID | OXF91T1-B31-16X33 |
| AWS Spec: | 5.29 |
| AWS Class: | E91T1-B3 |
| UNS Number: | W53031 |
| Welding Process: | FCAW |
Product Description
- All position flux cored wire recommended for welding 2-1/4 % Cr 1% Mo steels.
- The recommended shielding gas is CO2 or argon mixtures up to 75% Argon.
Documents
Technical
| Chemical Composition | ||||||
|---|---|---|---|---|---|---|
| C | Mn | Si | P | S | Cr | Mo |
| 0.05-0.12 | 1.25 max | 0.80 max | 0.03 max | 0.03 max | 2.00-2.50 | 0.90-1.20 |
| Mechanical Properties | |||
|---|---|---|---|
| Tensile Strength MPa (ksi) | Yield Strength MPs (ksi) | Elongation % | |
| AWS Requirements | 620-760 (90-110) | 540 (78) min | 17 min |
| Typical Results - As welded | 680 (99) | 630 (91) | 24 |
