Product Description

  • Designed for all-position welding
  • Provides superior weld performance and enhanced operator appeal.
  • Vacuum packaged
  • Certified Material Test Reports on all heats

Technical

Chemical Composition
CMnSiCrNiMoP
0.04 max0.5-2.51.0 max18.0-21.012.0-14.03.0-4.00.04 max
SCu
0.03 max0.75 max
Mechanical Properties
Tensile Strength
MPa (ksi)		Yield Strength
MPs (ksi)		Elongation
%
AWS
Requirements		520 (75) minNot specified20 min
Typical Results -
As welded		630 (91)470 (68)33
